Capsule Inspection Belt

S.NO

DESCRIPTION

SPECIFICATION

1.1

Name of the equipment

Capsule Sorting and inspection Belt (Two Operator)

1.2

No. of equipment required

1

1.3

Suggested capacity

100,000 Capsules per Hour

1.4

Classification

Design & Construction Compliant with cGMP

 TECHNICAL SPECIFICATION

S.NO

DESCRIPTION

SPECIFICATION

1.1

Conveyor belt

Conveyor belt should be PU food grade (Blue/green colour)

1.2

Belt

Minimum 150 mm wide and  2 mm thick

1.3

INFEED

Through Hopper

1.4

Hopper capacity

 Not less than 25 kg capacity capsule level in the hopper is easily visible to operator.

1.5

 Feeder Type

 Vibratory Feeder

1.6

Speed of the vibrator

Variable through potentiometer

1.7

Speed of the Belt

Variable through VFD

1.8

Two foot switches to be provided for Operators. First operator inspects one side of the Capsules and the second operator inspects the other side of the capsule.

1.9

CFL Inspection Lamp

1.10

Suitable Minimum size of the capsules 3 mm to Max size of the capsules 25 mm

1.11

No breakage the capsules at the time Tilting

1.12

Magnifying lens to be provided for better viewing

1.13

Providing angular guides on edge of conveyer make capsule to rotate 360degree.

1.14

Florescent inspection light to be provided with height adjustment.

1.15

Perforated vibratory plate for dust extraction to be provided.
